In addition to the available interfaces PROFIBUS, PROFINET, EtherNet/IP^TM, Modbus-TCP and EtherCAT^®, POWERLINK offers system designers the flexibility to use drive technology from SEW-EURODRIVE in all topologies. Both machine automation, e.g. motion control applications, and system automation with simple to complex conveyor technology can be implemented via POWERLINK.

Machine communication via POWERLINK is one of the most widespread real-time capable Industrial Ethernet communication technologies in the automation world and is based on the CAN in Automation standard CiA402. POWERLINK enables users to communicate in existing as well as in new systems that are equipped with BUSMASTER and thus to integrate the powerful control cabinet inverters from SEW-EURODRIVE.

The expansion in the area of control cabinet technology makes it possible to implement power ranges greater than 7.5 kW in systems with POWERLINK communication protocol. This completes SEW-EURODRIVE's powerful modular automation system, which now also includes control cabinet technology in addition to decentralized drives.

Products with POWERLINK communication variant

• Inverter series
  • MOVIGEAR^® performance
    • Features: Drive unit consisting of permanent magnet synchronous motor (IE5), integrated gear unit and frequency inverter
    • Power range: up to 2.1 kW
  • MOVIMOT^® advanced
    • Features: Drive unit consisting of DRN... series asynchronous motor (IE3), integrated frequency inverter and optional gear unit from the modular system
    • Power range: up to 2.2 kW / up to 7.5 kW in preparation
  • MOVIMOT^® performance
    • Features: Drive unit consisting of permanent magnet synchronous motor (IE5), integrated frequency converter and optional gear unit from the modular system
    • Power range: up to 1.88 kW / up to 4 kW in preparation
  • MOVIMOT^® flexible
    • Features: Decentralized inverter for installing the electronics close to the motor
    • Power range: up to 2.2 kW / up to 7.5 kW in preparation
  • MOVITRAC^® advanced
    • Features: Single-axis application inverter with own mains connection and direct fieldbus connection via pluggable fieldbus interfaces
    • up to 90 kW
  • MOVIDRIVE^® technology
    • Features: Single-axis application inverter with own mains connection and direct fieldbus connection via pluggable fieldbus interfaces
    • Power range: up to 315 kW

POWERLINK communication technology makes it possible to offer the MOVI-C^® automation modular system from SEW-EURODRIVE from a single source. From decentralized drive units to control cabinet inverters or industrial communication, there is always a consistent and coordinated solution - from the gear unit/motor with MOVILINK^® DDI to the inverter.
